Collet Chucks for Main & Sub Spindle, C-Axis Milling Capability, Auto Parts Catcher, Tool Presetter, Chip Conveyor, Torit Dry Flo Mist Collector, LNS Super Hydrobar 12 ft. Indexable Barrel Barfeed, Slant Bed Box Way Construction
Specifications:
Chuck Size 6"
Max Diameter Bar Capacity 1.7"
Max Swing Over Bed / Carriage 26.8" / 17.9"
Max Turning Diameter / Std 16.9" / 6.6"
Max Machining Length 13.7"
Distance Between Centers 24.8"
Spindle Motor 10 / 7.5 HP
Spindle Speed 60 - 6000 RPM
Spindle Bore 2.2"
Spindle Nose A2-5
Tools 12 (All Live)
Rapid Traverse Rates (X / Z) 708 / 945 IPM
X-Axis Travel 9.1"
Z-Axis Travel 20.5"
C-Axis Index .001 Degree
Milling Motor 3.5 HP
Milling Speed 3000 RPM
Sub Spindle Motor 10 / 7.5 HP
Sub Spindle Bar Capacity 1.3"
Turret Index (Single Step) 0.2 Seconds
Machine Dimensions (L x W x H) 91.3" x 73.7" x 72.5"
Machine Weight 9020 lbs.
FEATURES:
MORIC MSG-805 (MITSUBISHI) CNC CONTROL
10.4" Monochrome LCD
Collet Chucks for Main & Sub Spindle
C-Axis Milling Capability
Auto Parts Catcher
Tool Presetter
Chip Conveyor
Torit Dry Flo Mist Collector
Barfeed Interface
LNS Super Hydrobar 12 ft. Indexable Barrel Barfeed
Slant Bed Box Way Construction
