Dual Opposed Spindles with (2) Upper & (1) Lower Turrets, Y-Axis Milling Capability on All (3) Turrets, (12) Station Servo Driven Turrets with (24) Positions Each, Auto Parts Catcher "G", Parts Exit Conveyor, NT Nurse, Tool Life Management, Extended Macros, Multi-Tap Transformer, Coolant Thru Turret (1000 psi), on Both Upper Turrets, Coolant Thru Right Spindle, Iemca Prodigy 551-E Short 6 ft. Magazine Barfeed with Remnant Retract
Specifications:
Chuck Size 6.5" (2)
Max Diameter Bar Capacity (L & R) 1.65"
Max Swing Over Bed / Carriage 32.2"
Max Turning Diameter 6.89"
Distance Between Spindles 32.28"
Max Machining Length 23.15"
Tools 12 / 24 x 3 (12 live ea.)
Spindle Speed 6000 RPM
Spindle Bore 2.2"
Spindle Nose A2-5
Spindle Motor (L & R) 15 / 10 HP
Rapid Traverse Rates (X / Z) 640 / 1590 IPM
Milling Motor 9.5 HP
Milling Speed 6000 RPM
X1/X2/X3 Travel 5.3"
Z1/Z2/Z3 Travel (Upper / Lower Turret) 9.64" / 9.64" / 22.75"
Y1/Y2/Y3 Travel +/- 1.2"
C-Axis Index (L & R) .001 Degrees
Machine Dimensions (L x W x H) 109.5" x 77.6" x 76.4"
Machine Weight 17,636 lbs.
FEATURES:
FANUC SERIES 31i-TA CNC CONTROL
10.4" Color LCD
Dual Opposed Spindles with (2) Upper & (1) Lower Turrets
Y-Axis Milling Capability on All (3) Turrets
(12) Station Servo Driven Turrets with (24) Positions Each
Auto Parts Catcher "G"
Parts Exit Conveyor
NT Nurse
Tool Life Management
Extended Macros
Multi-Tap Transformer
Coolant Thru Turret (1000 psi) on Both Upper Turrets
Coolant Thru Right Spindle
Iemca Prodigy 551-E Short 6 ft. Magazine Barfeed with Remnant Retract
