Upper and Lower Turrets with Main & Sub Spindle, C-Axis Milling Capability on Both Turrets, Collet Chuck on Main Spindle, Tool Presetter, High Pressure Coolant Thru Turrets, LNS Quick Load Servo Short Magazine Barfeed, Turbo Chip Conveyor (Side Exit), Auto Parts Catcher, Parts Exit Conveyor (Type G), Three Color Tower Light
Specifications:
Chuck Size 6"
Max Diameter Bar Capacity 2"
Max Turning Diameter 9.84"
Max Machining Length 21.85"
Spindle Speed 59 - 4500 RPM
Spindle Bore 2.48"
Spindle Nose A2-5
Spindle Motor 20 HP
Tools 12 / 12
Rapid Traverse Rates (X / Z) 472 / 945 IPM
X-Axis Travel (Upper and Lower Turrets) 7.68"
Z-Axis Travel (Upper and Lower Turrets) 23.62"
C-Axis Index .001 Degrees
Sub Spindle Motor 10 HP
Sub Spindle Speed 4500 RPM
Sub Spindle Nose A2-5
Sub Spindle Bore 2.48"
Sub Spindle Travel 24.42"
Machine Dimensions (L x W x H) 135" x 82" x 78"
Machine Weight 16,600 lbs.
FEATURES:
FANUC 18iTB CNC CONTROL
10.4" Color LCD
Upper and Lower Turrets with Main & Sub Spindle
C-Axis Milling Capability on Both Turrets
Collet Chuck on Main Spindle
Tool Presetter
High Pressure Coolant Thru Turrets
LNS Quick Load Servo Short Magazine Barfeed
Turbo Chip Conveyor (Side Exit)
Auto Parts Catcher (Type G)
Parts Exit Conveyor
Three Color Tower Light
