Servo Driven Turret, NC Torque Limiter, Inch/Metric Switchable, Mac Man, Tool Nose Radius Compensation 2B, Expanded Auto Chamfering, Spindle Orientation Electronic, Auto Front Door, Tow-Along Tailstock, Hennig Chip Conveyor (Side Exit), Multi-Tap Transformer, Slant Bed Box Way Construction
Specifications:
Chuck Size 8"
Max Diameter Bar Capacity 2"
Max Swing Over Bed / Carriage 21.65" / 15.75"
Max Machining Diameter 10.63"
Max Machining Length 19.69"
Spindle Motor 15 HP
Spindle Speed 75 - 4200 RPM
Spindle Bore 2.44"
pindle Nose A2-6
Tools 12
Rapid Traverse Rates (X / Z) 591 / 787 IPM
X-Axis Travel 7.28"
Z-Axis Travel 20.47"
Tailstock Taper MT #5
Machine Dimensions (L x W x H) 147" x 70.9" x 66.9"
Machine Weight 9670 lbs.
FEATURES:
OKUMA OSP 700 CNC CONTROL
Serial Number 0151
10.4" Monochrome LCD
Servo Driven Turret
NC Torque Limiter
Inch/Metric Switchable
Mac Man
Tool Nose Radius Compensation 2B
Expanded Auto Chamfering
Spindle Orientation Electronic
Auto Front Door
Tow-Along Tailstock
Hennig Chip Conveyor (Side Exit)
Multi-Tap Transformer
(3) OD Wedge Blocks
Slant Bed Box Way Construction
