8" Hydraulic Chuck, Hydraulic Tailstock, One-Touch IGF Function, Chip Conveyor, Absolute Position Encoders, Inch/Metric Switchable, User Task 2, 1 MB Extended Memory, 3.5" Floppy Disc Drive, Nose Radius 2B, Cycle Time Calculation, Mac Man, Hi-G Control
Specifications:
Chuck Size 8"
Max Diameter Bar Capacity 2"
Max Swing Over Bed / Carriage 17.7"
Max Turning Diameter 10.60"
Max Machining Length 19.68"
Tools 8
Spindle Motor 10 / 7.5 HP AC
Spindle Speed 100 - 4200 RPM
Spindle Bore 2.44"
Spindle Nose A2-6
Rapid Travers Rates 591 / 787 IPM
X-Axis Travel 6.1"
Z-Axis Travel 20.47"
Tailstock Taper MT #5
Machine Dimensions (L x W x H) 120.5" x 66" x 67"
Machine Weight 8140 lbs.
FEATURES:
OSP U10L CNC CONTROL
9.5" Monochrome TFT
8" Hydraulic Chuck
Hydraulic Tailstock
One -Touch IGF Function
Chip Conveyor
Absolute Position Encoders
Inch/Metric Switchable
N/C Torque Limiter Protection
Graphic Animation
Lap 4
User Task 2
1 MB Extended Memory
3.5" Floppy Disc Drive
Nose Radius 2B
Expanded Auto Chamfering
Cycle Time Calculation
Thread Feed Hold
Mac Man
Hi-G Control
Three Color Status Light
Installed in August 2000
