One Touch IGF Function, Mac man, B42 Collet Chuck, Tailstock, Auto Parts Catcher, Servo Driven Turret, Integral Spindle Motor
Specifications:
Chuck Size 6"
Max Diameter Bar Capacity 1.63"
Max Swing Over Bed / Carriage 15.75" / 13.39"
Max Turning Diameter 6.69"
Max Machining Length 11.81"
Spindle Speed 50 - 6000 RPM
Spindle Bore 2.09"
Spindle Nose Flat
Spindle Motor 10 / 7.5 HP
Tools 12
Rapid Traverse Rates (X & Z) 1181 IPM
X-Axis Travel 6.89"
Z-Axis Travel 11.22"
Turret Index (Single Step) 0.2 Seconds
Tailstock Taper MT 4
Machine Dimensions (L x W x H) 79" x 64" x 70"
Machine Weight 7590 lbs.
FEATURES:
OKUMA OSP-U10L CNC CONTROL
10.4" Color LCD
One Touch IGF Function
Mac Man
B42 Collet Chuck
Tailstock
Auto Parts Catcher
Servo Driven Turret
Integral Spindle Motor
