4 axis machine with support spindle
C-axis, Y-axis
2x 12x turret with powered tools
appr. 40 tool holder and 32 tongs (6-40mm) and other accessories
onloading unit with belt conveyor
bar loader IEMCA CNC BOSS
chip conveyor
appr. 70000 power-on hours
turning diameter 160 mm
turning length 500 mm
control Fanuc 18 i
spindle bore 42 mm
work stroke - bed slide 200 mm
spindle turning speed - stepless 6000 U/min
feeds x + z axis stepless 20 + 30 mm/min
tool taper VDI 25
total power requirement 30 kW
weight of the machine ca. 5,5 t
dimensions of the machine ca. 9,30 x 2,30x 2,10 m
