28" swing over bed x 77", 117", 156" or 194" bc
Fanuc or Fagor controls operate in Semi-Manual, Automatic Cycle or G-Code modes (option)
15/21 HP main drive with CSS and 3-range autoshifting headstock
4.1" or 5.1" spindle bores with speeds up to 2000 RPM
16" wide TRI-V bed design
Independent swivel control station
Load capacity up to 4,600 lbs bc
Tailstock with 4.1" diameter quill, wrap around body and come-along
Easy operator’s controls, 4-way rapids, Americanized electronics and absolute encoders
Separate hydraulic power system for optional hydraulic chucks and steady rests
Wide range of options including power turrets, hydraulic chucks and steadies, chip conveyor, nesting doors, etc.
