63" swing over bed x 80" - 360" bc
Fagor 8055iTC or Fanuc 0iTD
40/50 HP main drive (50/60 HP option)
Extra heavy-duty 30" wide bed
Autoshifting 4-range headstock
Hardened and ground bed (48HRc) and cross slide ways
Hardened and ground gears, spindle and shafts (with auto lubrication)
Heavier design with 3.14" Z-axis ball screw ≥ 160" bc
Chip conveyor (front and rear) included as standard
TRI-V bed design with massive double-V guideways supporting carriage
Z-axis ball screw supported with built-in carriers (auto-positioning)
Carriage with anti-friction liners offering rapid feed rates up to 315 IPM
Hydraulic tailstock, heavy-duty 9.8" quill with “live” bearing
Wide range of options including chucks and steadies, turrets, spindle bores, guarding, spindle cooler, boring bar holder, Fanuc CNC, etc.
