65" swing over bed x 78" - 315" bc
2 or 3-way beds with front support way for apron
Siemens 840DSL Shop Turn or Fanuc 0iTD Manual Guide
Massive 40" / 43" wide bed, "solid" base from floor to front way, optional 4-way 3-shear bed
Big 5.5", 8.6", 12.5", 14.2" 17.7", 22" or 26" spindle bores
Up to 75 HP, load capacity up to 30,800 lbs
High speeds handle wider range (5.5" bore to 900 RPM)
3rd moveable hand wheel for easy toolsetting
Automatic shifting headstock
Gap bed allows swing up to 69" (TUR1550MN)
Full rear guarding and 1 front door guard
X-axis linear direct feedback scale standard
Z-axis linear measuring system for 236" and longer bc
Built-in chip conveyor standard
Rapids to 393 IPM reduces non-cut time
Heavy-duty tailstock rides on air cushion with come-along for operator ease
Large 7.9" diameter quill with built-in live center
Wide range of options including power or manual chucks, power turrets, live tooling with C and Y axes, hydraulic or manual steadies, hydraulic tailstock, special extra heavy-duty spindle or steadies, load capacity up to 80,000 lbs, 4-way 3-shear bed, etc.
