25" swing over bed x 78", 118", 157" or 236" bc
New guarding package controls chips and coolant while protecting operator
Siemens or Fanuc controls operate in Semi-Manual, Automatic Cycle or G-Code modes
16/25 HP main drive with CSS and 2-range headstock
4.1" or 5.5" spindle bores with speeds up to 2500 RPM
17" wide TRI-V bed design New overhead independent swivel control station
Up to 4,400 lbs bc (6,600 lbs with steadies)
Extended cross slide and saddle for stability and longer life Heavy-duty tailstock with
4" diameter quill, wrap around body and come-along
Easy operator’s controls, 4-way rapids, Americanized electronics and absolute encoder
New built-in hydraulic power system for optional hydraulic chucks and steady rests
Wide range of options including power turrets, hydraulic chucks and steadies,
C-axis with “live” tools, chip conveyor, nesting doors, 30 HP, etc.
