Coolant System
4 Live tool Holders
AC Drives and Motors
CATALOGUE SPECIFICATIONS:
Hole thru Spindle 3.03"
Chuck Diameter 8"
Spindle Nose A2-8
Swing Over Bed 19.69"
Max. Machining Diameter 11.02"
Max. Machining Length 19.69"
Max. Spindle Nose to Turret Face 27.91"
Min. Spindle Nose to Turret Face 5.87"
Turret Index Time, 0.5 Second
X-Axis Travel 8.07"
Z-Axis Travel 22.05"
Rapid Traverse Rate (X & Z) 472.4 IPM
Spindle Speeds, Infinite Range 35 to 3500 RPM
Rotary Tool Spindle Speed 30 to 3000 RPM
Rotary Tool , Horsepower 3 HP
Spindle Motor, Horsepower 10 HP
Overall Dimensions, L x D 106.3" x 60.63"
Overall Height 69.69"
Weight, Approximately 8378 LBS
