Max. Swing dia. over bed 2000mm
Max. Swing dia. over carriage 1600mm
center height 1030mm
Max. workpiece length 8000mm
Max. workpiece weight between centers 32T
max. torque of faceplate 8000kg.m
max. cutting force of single carriage 9000kg
total cutting force 16000kg
Cone point angle of center and specification 75°ф100 taper 1:7
Section dimension of tool shank 70*70mm
Step No. of spindle speed stepless
range of spindle speed 0.8-160 r/min
Taper bore in spindle ф120mm taper 1:7
Dia. Of face plate 2000mm
Step No. of speed 18 steps
Range of longitudinal feed 0.125-48mm/1 spindle rotation
Range of cross feed 0.063-24mm/1 spindle rotation
Feed range of tool slide compound 0.063-24mm/1 spindle rotation
Longitudinal rapid traverse speed 3000mm/min
Cross rapid traverse speed 1500mm/min
Max. travel of cross slide 725mm
Max. travel of tool slide compound 600mm
Pitch of metric threads 2-40mm
inch threads (pitch/inch) 1-14
modul threads 1.5-20mm
Dia.of tailstock sleeve 300mm
Travel of tailstock sleeve 300mm
Spindle taper bore of tailstock ф100mm taper 1:7
Rapid traverse of tailstock 3000mm/min
Rapid traverse of sleeve 664mm/min
Dia. range of closing steady rest 400-750mm
Dia. range of open steady rest 650-1200mm
Power and rotate speed of main motor 75KW 400-1500r/min
Power and rotate speed of the motor of tool post rapid traverse 1.5kW 1410r/min
Power and rotate speed of the motor of tailstock Rapid traverse 1.5kW 1410r/min
Power and rotate speed of the motor of tailstock sleeverapid traverse 1.1kW 1410r/min
Power and rotate speed of the motor of lubricating pump of headstock1.1kW 1410r/min
Overall dimension of machine(L*W*H) 13577*2479*2480mm
Weight of machineabout 55T
