Order No.
AMT6230X750
Max.swing over bed
310mm
Max.swing over cross slide
180mm
Max.swing in gap
450mm
Distance between centers
750mm
Spindle bore
38mm
Taper of spindle bore
M.T.#5
Range of spindle speed
65-1400rpm
(65-1810rpm optional)
Range of longitudinal feeds
0.0527-1.2912mm/rev
Range of cross feeds
0.011-0.276mm/rev
Range of metric threads
0.4-7mm
Range of inch threads
4-60TPI
Taper of tailstock bore
M.T.#3
Power of motor
1.1kw.3PH/1.5kw.1PH
Packing size
1480x750x1420mm
N.W./G.W.
510Kg/609Kg
