Swing Over Bed
460mm(18")
Swing Over Cross Slide
274mm(10-3/4")
Swing In Gap
690 mm(27-1/8")
Length Of Gap
155mm(6-1/8 〞)
Max.Length Of Workpiece
1000mm(60 〞)
Bed Width
300mm(11-13/16 〞)
Spindle Nose
D1-6
Spindle Bore
58mm(2-1/4 〞)
Taper Of Spindle Bore
NO.6Morse
Range Of Spindle Speed
12changes25-2000r/min
Max.Travel Of Compound Rest
120mm(4-3/4〞)
Max.Travel Of Cross Slide
290mm(11-3/8〞)
Leadscrew Pitch
4T.P.I.
Max. Section Of Tool
25mm×25mm(1×1〞)
Longitudinal Feeds Range
42kinds 0.031-1.7mm/rev
(0.0011〞-0.0633〞/rev)
Cross Feeds Range
42kinds 0.014-0.784mm
(0.00033〞-0.01837〞)
Metric Threads Range
41kinds 0.1-14mm
Inch Threads Range
60kinds 2-112T.P.I.
Diametrical Pitches Range
50kinds 4-112D.P.
Module Pitches Range
34kinds 0.1-7M.P.
Dia. Of Tailstock Sleeve
60mm(2-5/16〞)
Travel Of Tailstock Sleeve
120mm (4-3/4〞)
Morse Taper Of Tailstock Sleeve
NO.4 Morse
Power Of Main Motor
4kw(5.4HP),
optional 5.5kw(7.5HP)3PH
Power Of Coolant Pump
0.1kw(1/8HP).3PH
Net Weight/Gross Weight
1970/2320kg
Packing Size
2250x1120x1700mm
