25"/33" x 120" Barcorp Preci-Turn Gap Bed Engine Lathe
Specifications:
25"/33" x 120" Barcorp Preci-Turn Gap Bed Engine Lathe
S/N: 1091214 New: 1980
EQUIPPED WITH:
Removable Gap In Bed. In/Mm Threading. Heavy Duty Cross Slide With Power Rapid Traverse. 4-Way Tool Post. Inch Ready Dials. Heavy Duty Tailstock With Handwheel Adjustable Quill. 12" 3-Jaw Chuck. 20" Face Plate. (2) Steady Rests. (1) Follow Rest. Coolant Pump And Tank. Splash Guards.
SPECIFICATIONS:
Center Height 12.40"
Max. Turning Dia. Above Lathe Bed 25.98
Max. Turning Dia. in Recess 33.07
Max. Turning Dia. Above Slide 16.34"
Max. Center Distance 118"
Bed Width 19.30"
Bore of Main Spindle 3-3/8"
Inner Cone of Spindle Metric 80
Camlock 8" D1 Type Nose ASA B 5.9-1967
Spindle Drive 15 kw (27 HP)
Spindle Speeds (24) 9-1400 RPM
Taper of Centers Morse 5
Longitudinal Movment of Tailstock Sleeve 9.84"
Speed of Slide (Rapid) 0.157 IPM
Range of Longitudinal Feed (42) 0.0017-0.1900 IPR
Range of Cross Feed (42) 0.0009 - 0.095 IPR
Metric Thread (35) 0.5 - 48
Module Thread (30) 0.25 - 24
Whitworth Thread (42) 48-7/16
Diametral Pitch Thread (42) 96-7/8 DP
Circular Pitch Thread (20) 1-1/16" - 3 CP
Approximate Weight 10,000 lbs
