Description:
Distance between centers, mm 3000
Diameter with GAP, mm 1000
Specifications:
Distance between centers, mm 3000
Swing Over Bed , mm 800
Swing Over Cross Slide , mm 520
Diameter with GAP, mm 1000
BED WIDTH , mm 550
Spindle Speeds (18 position.), rpm 7,5 -1000
Bar Capacity , mm 105
LONGITUDINAL FEEDS, IPM 0,1-24,3(64)
Cross FEEDS, IPM 0,05-12,15(64)
Метрическая резьба, мм 1-240(39)
Power main motor , kW 11
Overall Dimensions , mm 4480х1100х1920
Weight , kg 4330
Dimensions:
Overall Dimensions , mm 4480х1100х1920
Weight:
Weight , kg 4330
