This machine is in very good condition and rebuilt in recent years
Specifications:
Control Traub TX 8H
Main spindle speeds: 63 - 6300
Feeding force at 63 % ED 4,6 KW
Feeding force at 25 % ED 7,4 KW
Z-axis 200 mm
X-axis 60 mm
Number of toolholder-holes 8
Number of driven axis 7+1 Synchron spindle
Tools speed 300 - 6000 U/min
Number of cutoff tool slide 4
Cutoff tool slide -travel 43 mm
Work stroke 17 mm
Rapid traverse 15 (Stechschlitten) m/min
Gripping spindle 26 mm
Bar material dia. max. 28 mm
Drive unit - cutting side
Longitudinal stroke 85 mm
Rapid traverse 30 m/min
Bar loader Stamag 3000 / 28
Connected load 15 kW
Weight of the machine ca. 2,40 t
Dimensions of the machine ca. 6,45 x 0,95 x 1,65 m
Additional information
Control TX 8 H
Bar loader Stamag 28 mm / 3000 mm
Powered tools inside revolver
C-axis
Powered tools for back side machining
