Work area length 1000 mm turning diameter over bed (max.) 356 mm turning diameter over support (max.) 220 mm turning diameter over bridge (max.) 506 mm X-axis 178 mm travel Z1-axis 92 mm bridge length 206 mm Width of bed 206 mm swing area Upper slide 50 Main spindle speed (16) 45 - 1800 min-1 spindle bore 38 mm spindle taper Camlock D1-4 spindle cone MK 5 Feed feed X-axis from 0.015 to 0.22 mm / rev feed Z-axis from 0.043 to 0.653 mm / rev tapping thread cutting, Metric (37) 0.4 to 7 mm Tapping, Whitworth (28) 4-56 GPZ tailstock tailstock quill 45mm Tailstock Tailstock taper MT 3 120 mm Reitstockqürverstellung 10 mm / 0.4 "drive power motor rating main drive (cont./30 min) 1, 5/2, 4 kW / 2/3 hp supply voltage 400 V, weights and dimensions 1945x785x1204 mm Weight 880 kg
