Number of spindles: 6
Maximum diameter locking: 160 mm
Max. turning length: 125 mm
Max. stroke of long slide: 150 mm
Number of tools: 11
Spindle speeds:
number (steps): 17
from 129 rpm
up to 1165 rpm
Production time: 8-365 s.
Voltage 50 Hz 3x 380 Volt
Power 17,5 kW
Machine's weight about 10200 kg
Overall dimensions machine:
Length: 3850 mm
Width: 1350 mm
Size seaworthy: 16 mc.
Various accessories.
