Max turning diameter from 65 mm bar
Max turning diameter 250 mm cameras
Max working length 500 mm
Max 520 mm diameter rotating
CHUCK:
Range of variable rotation speed / 1 '40-4000
Spindle nose - ASA 6 ''
Spindle hole 80 mm
Internal diameter front bearing 110 mm
Chuck diameter mm 210/250
Motor power kW 22/26
TOWER:
Number of Positions - 12
Type - Bidirectional
Stem tool for external mm 25 x 25
ACES:
X axis travel 210 mm + 5
Z-axis travel mm 500 + 10
Rapid X axis m / min 20
Quick Z axis m / min 24
MOTORIZED TOOLS:
Rotation range max revs / min 50-3000
Motor power 3.7 kW
AXIS C CONTROLLED:
Type - CS (Direct)
Minimum programmable value - 0.001 °
Rapid speed rev / min 80
TAILSTOCK HYDRAULIC:
Corsa automatic tube 100 mm
Tube diameter 85 mm
Cone chuck - CM 4
Positioning automatic / manual mm 510-440
REFRIGERANT:
Tank capacity 200 lt
Pump capacity lt / min 100
DIMENSIONS - WEIGHT:
Machine with chip conveyor mm 4000 x 1940 x
h 1960
Weight with chip conveyor kg 4700
year 2001
