XZ axis travel 560/1100
axis travel u / w 275/12750
engine power with two ranges kw 51/68
spindle speed 2000 rpm
torque 1290 Nm
A spindle nose 11
upper turret VDI 50
DIN 69893 12 positions
lower turret VDI 40
DIN 69893 12 positions with 3 motorized supplied
tailstock automatic movements and blocking with 90 mm diameter sleeve
115 mm stroke
push 12700
chip conveyor to carpet
