Circulation over bed: 480 mm Swing over cross slide: 200 mm height and bed guide rail: 240 mm Width: 333 mm stroke length: 902 mm stroke width: 225 mm Cross travel / turning length: 290 / 1000.2000 spindle size DIN 55022: 6 Spindle Bore: 56 mm Chuck diameter: 180/230 mm spindle in front bearing 90 mm drive power, 11 kW Max torque on spindle d: 1120 Nm Speed range 31.5 -2240 min feed Z-feed spindle / pitch: 36/10 X-feed spindle / slope: 25 / 5 mm Z rapid traverse / feed speed: 5-8 m / min rapid traverse X / speed: 5-8 m / min tailstock quill: 65mm Quill stroke: 155 mm Quill Recording: MK 4 machine length: 2930 x 1870 x 1805 Machine weight: 2200kg
