Work in the area has the following characteristics
turning diameter 330 mm
rotary diameter 600 mm
Maximum Turning length 500 mm
Number of stations 12
VDI 40
motor speed 3000 rpm
Motorized Power kw 5.5 The counter has the following features
Spindle nose ASA A2-5
Chuck diameter 165 mm
Spindle speed 35-4500 rpm
3212X1730X1980 length dimension
