First ownership from German wholesale company. Location: Werkstinstandhaltung. Very well maintained condition. Few hours of operation.
Optional equipment and accessories:
- Support in reinforced design with self-transition the upper Support for taper turning for 200 mm displacement of the upper slide
- Reinforced main spindle, spindle head with centering and bayonet plate mounting Gr. 11 DIN 55022
- Spindle bore 103 mm
- Motor power 22 kW
- Quick-change tool holder multifix Gr. C
- 5 piece steel bracket inserts
- 2-axis digital display Heidenhain for the longitudinal and transverse axis
- Pneumatic clamping equipment manufac Forkardt with clamping cylinder PZLAJ 250 without passage
- Steady rest with roller and sliding jaws, diameter 180-400 mm
- Rapid traverse longitudinal and transverse
- Micrometric fence
- 3-jaw chuck Manufacturer Rohm, diameter 500 mm with split jaws, bore 190 mm
- 4-jaw chuck Manufacturer Rohm, diameter 315 mm
- 4-jaw independent chuck Manufacturer Rohm, diameter 630 mm
- Complete Techical Documentation in German language
Specifications:
turning diameter over bed 640mm
turning diameter over slide rest 385mm
turning lenghts 2000mm
spindle bore 103mm
power requirement 22kW
