Max processing diameter over bed: 400 mm
Max processing diameter over support: 220 mm
Max processing diameter in recess of bed: 400 mm
Max distance between centers: 1000 mm
Front end of spindle according to DIN: 6К
Diameter of cylindrical spindle bore: 55 mm
Size of conical spindle bore: Morze 6
Number of spindle rotation speeds: 23
Working range of revs: 12,5-1600 rpm
Main drive power: 11 kW
Number of feeds: 42
Longitudinal feeds range: 0,05-2,8 mm/rev
Transversal feeds range: 0,002-0,11 mm/rev
Metric thread: 0.5...192 mm
Inch thread: 24...1.625
Modular thread: 0.5...48
Pitch thread: 96-1
Sleeve stroke: 200 mm
