Machine fully modernized and modified of SEDIN 1L532 with new electrical and lubrication unit, painted, replacement of damaged mechanical parts, with possibility of upgrading. The upgrade is made of cast iron, on request we can equip the machine with the new CNC control SIEMENS SINUMERIC 828. Machine controlled by only one carriage.
Machine builts on customer request.
Delivery time: max. to 6 - 7 months
Technical details
Number of columns: 2
Number of carriage:
1
Type of carriage:
RAM
Number of axis controlled:
X/Z
Turning diameter:
4000mm
Table diameter:
2800mm
Max. workpiece height:
1600mm( with possibility of upgrading to 2200mm)
Max. table load: 16 000kg
Table speeds range: 70rpm
Number of table speeds range: 3
Vertical travel in Z axis 1200mm
Horizontal carriage travel in X axis: 2120mm
Work feeds range: 2-2000mm/min
Rapid feeds in X/Z axis: 10m/ min
Knife intersection: 63 x 40mm
Traversal beam vertical travel: 1240mm
Traversal beam feed: 360mm/min
Main motor power: 55kW
Installed power: 69kW
Positioning accuracy: 0,01-1000mm
Machine dimension: 5500 x 6750 x 4900mm
Net weight: 49000kg
