1999
CNC Mori seiki MSC-518
TECHNICAL FEATURES:
CAPACITY ':
-Diameter Admitted over bed 600 mm
-Max Turning diameter 450 mm
-Diameter Turnable standard 355 mm
RACES:
-AXIS Mm X 255 (225 + 30)
-AXIS Z mm 470
CHUCK:
-Speed 'Spindle rpm 30-3000
-gamma Spindle speed 1
JIS A2-8 spindle -Naso
-Hole Spindle 61 mm
-Diameter Internal front bearing 130 mm
TOWER:
-Number Tools 8
Section-tool 25 mm
-Diameter Boring bar max 50
ADVANCEMENT:
-Avanzamenti Rapid mm / min
X / Z: 24000/20000
-Avanzamenti Mauale in mm / min 0-1260
-Search Main (30min / continuous) 18.5 kW / 15
WEIGHT AND DIMENSIONS MACHINE:
-height Of the machine mm 2443
-Space Required mm 1854x3200x2794
-Weight Kg 7500
