YOM: 1989
Type: double column
Origin: Romania
Manufacturer: Umaro SA
Specifications:
Table diameter: 1450 mm
Swing: 1650 mm
Max swing with side head: 1550 mm
Max working height: 1200 mm
Max workpiece weight: 8000 kg
Cross rail vertical travel 1000 mm
Right head vertical stroke: 760 mm
Left head vertical stroke: 1000 mm
Table speed range: 2-200 rpm
Main spindle speed range: 2.22-200 rpm
Main motor: 60 kW
Dimensions:
-Height: 4500 mm
-Length: 4500 mm
-Width: 4700 mm
Machine weight: 20500 kg
