Made: UTITA
Model: TV 1800 CN
Autocentering spindle: Oleodinamic 4 jaws
Engine power: 59 Kw
Extra: CE nel 2010, ingombro 4650x4400x6210
Manufacturer: ECS
Max height: 1900 mm
Max tools dimension: 32 - 40 mm
Max weight on the table: 16000 kg
Max. torque: 19000 Nm
Model: 1802
N. of ranges: 2
New in: 1998 Overhauled and retrofitted in 2008
Ram size: 250 mm
Ram stroke: 1010 mm
Table capacity: 1800 mm
Table capacity: 2050 mm
Tool changer: 12
Vertical traverse stroke: 1400 mm
Weight: 26400 Kg
Spindle speed: 160 Rpm
Drilling diameter: 2050 mm

-
