SERIAL ............................. 22739
MODEL .............................. 74" CUTMASTER
DIAMETER OF TABLE .................. 74"
SWING WITH SIDE HEAD UP ............ 78"
SWING WITH SIDE HEAD DOWN .......... 82"
TABLE SPEEDS ....................... 1.6 TO 60 RPM
FEEDS .............................. .0026 TO .500
DISTANCE UNDER RAIL ................ 62"
TURRET RAIL HEAD ................... YES
TRAVEL OF HEAD ON RAIL ............. 50-3/8"
VERTICAL TRAVEL OF TURRET HEAD ..... 30-3/8"
SIDE HEAD .......................... YES
VERTICAL TRAVEL OF SIDE HEAD ....... 52-5/8"
HORIZONTAL TRAVEL OF SIDE HEAD ..... 27"
FLOOR TO TOP OF TABLE .............. 36"
MAIN MOTOR ......................... 30 HORSEPOWER
