CNC can be installed by the requiest of the clients.
Specifications:
Item
Dia. Of Table 4500mm
Max swing5000mm
Max working piece height3150mm
Max load 32T
Max cutting force of right tool holder40kN
Max cutting force of left tool holder35kN
Total cutting force63 kN
Max Table torque 80 kN.m
Speed of the table16 gear
Speed range of the table1.25 – 40 RPM
Tool holders’ working travel 0.1 – 500mm/min
Max travel range of tool holdersHorizontal -20 – 2765mm
Vertical 1250mm
Dimension of the ram 220 * 220mm
Rapid travel of the tool holder 4000mm/min
Travel of the horizontal guide 2200mm
Travel speed of the horizontal guide350mm/min
Main motor 55 KW
Tool holders Horizontal travel AC servo motor48Nm
Tool holders vertical travel AC servo motor
Weight of the machine95T
Demission of the machine 12960* 6531*7635
