Introduction：
◎ Used for connector of aluminum profile cutting.
◎ Automatic feeding system controlled by PLC, result high efficiency.
◎ Recording system record the number that already cut.
◎ Imported carbide saw blade gives accurate processing, and high durableness.
◎ It has features of high automation, reliability and efficiency.
Specifications:
Technical Parameter：
Model LJMJ-500
Input voltage 380V/50Hz
Input power 2.2Kw
Air pressure 0.5~0.8MPa
Air consumption 150L/min
Motor rotation speed 2840r/min
Saw blade standard φ500×4.4×φ30×Z120
Saw feeding speed 0~3m/min
Cutting height 120mm
Auto feeding length 3~400mm
Overall dimension 2000×1600×1400mm
