Description:
Amera-Seiki, AH-1000, 82.7"-X x 48.6"-Y x 48.6"-Z, 35HP/geared, 6000rpm, 90-ATC, CT-50, CTS-610 PSI, 1-degree index on axis, 39.4pallets, Fanuc 0i-MD control, September installation to customer! 4 weeks out, todays date 8-20-2012
Specifications:
Amera-Seiki AH-1000,w/Fanuc 18i-MB Control, 82.7X, 48.6Y, 48.6Z,35HP,CT-50,6,000rpm,Oil Chiller,2-speed ZF Gearbox,Coolant Thru Spindle w/2-Stage Filtration-High Pressure(610 psi),Twin Augers w/belt lift up type Chip Conveyors, X,Y&Z Oil Chilled Ball-screws,Rigid Tapping,Full enclosure w/top,90-Tool ATC,1 degree pallet index,T-slotted pallets,2-Year Parts warranty on machine, 200-work offsets, Spare M-codes,400 part programs, 1280M program memory,1-GB Data Server & Fast Ethernet Communications,400-tool offsets,High speed skip function,Helical Interpolation, Tool Life Management, Tool length measurement,delivery in Sepember/2012, available Now for Sale
Dimensions:
230" x 320" x 156"
Weight:
70,400 LBS
