Helical Interpolation, Rigid Tapping, Turbo Chip Conveyor, Remote Manual Pulse Generator, Yellow Operation End Light, Heavy Duty Box Way Construction

Pallet Size 19.7" (2)
Travel: X-Axis 31.5"
Y-Axis 25.6"
Z-Axis 25.6"
Pallet Index 1 Degree
Spindle Speed 20 - 5000 RPM
Spindle Taper Cat 50
Spindle Motor 20 / 15 HP
Spindle Center to Table Top 2.0" - 27.6"
Spindle Nose to Table Center 5.9" - 31.5"
Spindle Torque 600 ft. lbs.
Tools 40
Rapid Traverse Rates (X / Y & Z) 709 / 591 IPM
Gear Ranges 3
Pallet Change Time 15 Seconds
Pallet Load Capacity 1764 lbs.
Tool Change Time (T - T) 5 Seconds
Max Tool Diameter 5.3" / 9.8"
Max Tool Length 15.7"
Max Tool Weight 55 lbs.
Machine Dimensions (L x W x H) 118" x 204.7" x 119.7"
Machine Weight 27,577 lbs.


FEATURES:
FANUC 15M CNC CONTROL
9" Monochrome CRT
Helical Interpolation
Rigid Tapping
Turbo Chip Conveyor
Remote Manual Pulse Generator
Yellow Operation End Light
Heavy Duty Box Way Construction

118 x 205 x 120

27577
