Rigid Tapping, 90 Tool Magazine, Fourth Axis Rotary Table, Coolant Thru Spindle (1000 psi), Turbo Chip Conveyor (Front Left Exit), Spindle Chiller Unit, Remote Manual Pulse, Three Color Tower Light, Heavy Duty Box Way Construction
Specifications:
Pallet Size 31.5" (2)
Travel: X-Axis 49.2"
Y-Axis 39.4"
Z-Axis 39.4"
Pallet Index .001 Degrees
Spindle Speed 6000 RPM
Spindle Taper Cat 50
Spindle Motor 30 HP
Spindle Torque 1237 ft. lbs.
Spindle Center to Table Top 3" - 42.3"
Spindle Nose to Table Center 7.9" - 47.2"
Tools 90
Rapid Traverse Rates (X, Y & Z) 945 IPM
Tool Change Time (T - T / C - C) 2.5 / 9.0 Seconds
Pallet Change Time 29 Seconds
Pallet Load Capacity 3520 lbs.
Max Tool Diameter 5.3" / 9.8"
Max Tool Length 21.7"
Max Tool Weight 57 lbs.
Machine Dimensions (L x W x H) 278" x 165.4" x 131.1"
Machine Weight 39,683 lbs.
FEATURES:
FANUC 16i-MA CNC CONTROL
10.4" TFT
Rigid Tapping
90 Tool Magazine
Fourth Axis Rotary Table
Coolant Thru Spindle (1000 psi)
Turbo Chip Conveyor (Front Left Exit)
Spindle Chiller Unit
Remote Manual Pulse Generator
Three Color Tower Light
Heavy Duty Box Way Construction
