x-travel 1200 mm
y-travel 680 mm
z-travel 600 mm
clamping range 1100 x 250 mm
angular adjustment of indexing table 360 x 1 °
no. of tools in the magazine 4 x 25 Stück
max. tool diameter 63 mm
max. tool length 250 mm
change-time tool to tool 4 x 2 sec
distance work spindle /surface of the table 600 mm
distance table-horizontal spindle + / - 340 mm
spindle taper ISO 40
spindle turning speed range 45 - 4500 U/min
feed stepless 15000 mm/min
rapid travel x/y/z 15000 mm/min
workpiece weight 4 x 250 kg
voltage 380 V
spindle motor 25 kW
weight of the machine ca. 26 t
dimensions of the machine ca. 10 x 7 x 3,6 m
