Specifications:
Pallets: 2
Pallet Size: 15.7" x 15.7"
Max Weight On Pallet 880 LBS
Travel: X 23", Y 18" Z 20"
Spindle RPM: 10,000
Automatic Tool Changer: 100 Station
Spindle Taper: BT 40 CV43
Distance Table Center to Spindle Nose: 6" to 26"
Distance Table Surface To Spindle Center: 2" to 20"
Rapid Traverse: 945 IPM
Motor: 15/20 HP AC
Equipped With:
New Spindle Motor
Chip Conveyor
Flood Coolant and Coolant Through Spindle
