KITAMURA HX300, 2000, 20.1"X, 20.1"Y, 15.7"Z, full 4th, chip conveyor, 10000 RPM

General specifications as per brochure

Specifications:
Pallet:
Pallet Size (2 pallets): 12" x 12"
Pallet indexing / table load: 360,000deg / 550lbs
Travels:
X-axis tarvel: 20.1"
Y-axis travel: 20.1"
Z-axis travel: 15.7"
Spindle:
Spindle speeds min./max.: 50/10,000 rpm
Spindle taper: 40 taper
Main motor (30min / continuous): 20 / 15hp
Spindle center to table top: 2.1" - 24.8"
Tool changer:
Tool changer positions: 40 atc
Tool change time (T/T, C/C): 1.3 / 3.9 sec
Rapids:
Rapid traverse (X,Y&Z): 1,417 ipm
Feed rate: 0.01 - 630 ipm
Dimensions
Floor space (LxWxH): 150" x 84" x 101"
Weight (approx.): 15,400 lbs

Equipped with (must be verified by buyer)
Fanuc 18i CNC Control
Thru spindle coolant
Box ways
(2) Bock tombstones
Chip conveyor
Tool setter touch probe (non-functional)

19580 (LBS)
