1 used Horizontal Machining Center
Make MAUSER
mod. PS 800 S
new 1996 with NUM-760
Workrange: 1000 x 1000 x 900 mm
main motor: 22/27 kW
Equipment:
4. axis CNC-Rotary table 360 x 0,001°,
4 Palets 800 x 800 mm.
120-station Tool changer (2 x 60 station Chain),
High Pressure Unit for Internal Cooling,
- no Cooling-Tank - ( Central Suply )
Oil Dust Suction
Remarks:
Spindle SK-50, Speed range 45-6000 min-1,
Feed rate 1-15000 mm/min., Rapid feed 15 m/min
Table load 1800 kg, Swing-Diameter 1000 mm.
Distance Spindlenose - Table-Middle 200-1100 mm
Distance Spindlecenter - Tablesurface 90-1090 mm
measurements approx. 8 x 6,5 m
