Auto Tool Length Measurement, Niagara Flood Coolant, Rigid Tapping, Coolant Thru Spindle, 80 Tool Magazine, 25000 RPM Spindle Speed, Spindle Chiller Unit, Multi-Tap Transformer, Concept 2000 Chip Conveyor (Rear Exit), Coolant Thru Ball Screws

Pallet Size 15.75"
Travel: X-Axis 22.05"
Y-Axis 24.02"
Z-Axis 22.05"
Pallet Index 1 Degree
Spindle Speed 25,000 RPM
Spindle Taper Cat 40
Spindle Nose to Table Center 5.91" - 27.95"
Tools 80
Main Motor 30 / 20 / 15 HP AC
Number of Pallets 2
Rapid Traverse Rates 1968 IPM
Tool Change Time (C - C) 5 Seconds
Pallet Load Capacity 880 lbs.
Max Tool Diameter 3.74" / 5.9"
Max Tool Length 12.6"
Max Tool Weight 26.4 lbs.
Machine Dimensions (L x W x H) 105.6" x 169.8" x 103.8"
Machine Weight 20,793 lbs.


FEATURES:
MAZATROL FUSION 640M CNC CONTROL
10.4" Color LCD
Conversational Programming
EIA/ISO Input Function
3.5" Floppy Disc Drive
1 MB Memory
Auto Tool Length Measurement
Niagara Flood Coolant
Rigid Tapping
Coolant Thru Spindle
80 Tool Magazine
25000 RPM Spindle Speed
Spindle Chiller Unit
Multi-Tap Transformer
Mayfran Concept 2000 Chip Conveyor (Rear Exit)
Coolant Thru Ball Screws

105 x 170 x 104

20793
