Pallet Size 15.75"
Travel: X-Axis 22.05"
Y-Axis 20.08"
Z-Axis 20.08"
Pallet Index 1 Degree
Spindle Speed 50 - 10,000 RPM
Spindle Taper Cat 40
Spindle Motor 15 / 10 HP
Spindle Nose to Table Center 3.94" - 24.02"
Spindle Center to Table Top 1.18" - 21.26"
Tools 30
Number of Pallets 2
Pallet Load Capacity 880 lbs.
Rapid Traverse Rates 1180 IPM
Max Tool Diameter 3.74" / 5.91"
Max Tool Length 11.8"
Max Tool Weight 26.4 lbs.
Machine Dimensions (L x W x H) 151.6" x 98" x 95.6"
Machine Weight 18,700 lbs.
FEATURES:
MAZATROL M-32A CNC CONTROL
14" Color CRT
Conversational Programming
EIA/ISO Input Function
Coolant Thru Spindle
Auto Tool Length Measurement
Tool Life Management
Rigid Tapping
Helical Interpolation
Niagara Flood Coolant
Dual Chip Augers
Chip Conveyor
(2) Tombstones
Mfg Date November 1991
