Pallet Size 31.5" (2)
Travel: X-Axis 39.37"
Y-Axis 33.46"
Z-Axis 32.28"
Pallet Index 1 Degree
Spindle Speed 35 - 12,000 RPM
Spindle Taper Cat 50
Spindle Motor 40 / 33.5 HP
Spindle Torque 310 ft. lbs.
Spindle Center to Table Top 1.2" - 34.6"
Spindle Nose to Table Center 7.9" - 40.2"
Tools 40
Pallet Load Capacity 2424 lbs.
Max Tool Diameter 4.72" / 9.45"
Max Tool Length 19.69"
Max Tool Weight 55 lbs.
Machine Dimensions (L x W x H) 180" x 136" x 130"
Machine Weight 40,000 lbs.
FEATURES:
FANUC 16iM CNC CONTROL
10.4" Color LCD
Coolant Thru Spindle (1000 psi)
Rigid Tapping
Chip Conveyor
Chip Auger
Remote Manual Pulse Generator
Spindle Chiller Unit
