Coolant Thru Spindle (1000 psi Vega 1002), 50 Tool Magazine, Rigid Tapping, Turbo Chip Conveyor (Front Left Exit), Remote Manual Pulse Generator, Daikin Spindle Chiller Unit, Two Color Tower Light, Overhead Coolant Wash, Multi-Tap Transformer
Specifications:
Pallet Size 15.75" (2)
Travel: X-Axis 22.05"
Y-Axis 20.08"
Z-Axis 22.05"
Pallet Index 1 Degree
Spindle Speed 100 - 12,000 RPM
Spindle Taper Cat 40
Spindle Nose to Table Center 5.91" - 27.95"
Spindle Center to Table Top 1.97" - 24.02"
Spindle Motor 30 / 25 HP
Tools 50
Rapid Traverse Rates 1574 IPM
Pallet Load Capacity 880 lbs.
Pallet Index Time (90 Degrees) 1.5 Seconds
Pallet Change Time 5 Seconds
Max Workpiece Dia Height 24" / 38.4"
Tool Change Time (T - T / C - C) 1.0 / 3.4 Seconds
Max Tool Diameter 3.23" / 5.51"
Max Tool Length 11.81"
Max Tool Weight 17.6 lbs.
Machine Dimensions (L x W x H) 157" x 87.9" x 114"
Machine Weight 19,700 lbs.
FEATURES:
NEOMATIC 530 (MITSUBISHI) CNC CONTROL
9" Monochrome LCD
Coolant Thru Spindle (1000 psi Vega 1002)
Turbo Chip Conveyor (Front Left Exit)
50 Tool Magazine
Rigid Tapping
Remote Manual Pulse Generator
Daikin Spindle Chiller Unit
Two Color Tower Light
Overhead Coolant Wash
Multi-Tap Transformer
