Helical Interpolation, Rigid Tapping, Two Color Tower Light, Dual Chip Augers
Specifications:
Pallet Size 19.7" (2)
Travel: X-Axis 28"
Y-Axis 24"
Z-Axis 25"
Pallet Index 1 Degree
Spindle Speed 4000 RPM
Spindle Taper Cat 50
Spindle Motor 25 HP AC
Spindle Nose to Table Center 2" - 26"
Spindle Center to Table Top 6" - 31"
Tools 40
Tool Change Time (T - T) 1.3 Seconds
Pallet Change Time 6 Seconds
Pallet Load Capacity 2200 lbs.
Rapid Traverse Rates 945 IPM
Max Tool Diameter 4.5" / 9"
Max Tool Length 17.7"
Max Tool Weight 44 lbs.
Machine Dimensions (L x W x H) 194" x 120" x 115"
Machine Weight 23,148 lbs.
FEATURES:
OKK NEOMATIC (MITSUBISHI) CNC CONTROL
9" Monochrome CRT
Helical Interpolation
Rigid Tapping
Two Color Tower Light
Dual Chip Augers
