Still under power in plant. New Control 2001

max. workpiece dia. 800 mm
max. stroke 300 mm
no. of teeth range 16 - 240
module range 1,5 - 8
helix angle +/- 30 °
pressure angle range 14 – 30 °
max. workpiece weight 300 kg

max. grinding wheel dia. 400 mm
min. grinding wheel dia. 280 mm
grinding heel width 84/104 mm

grinding wheel speed:
- grinding 1650 rpm
- profiling 90 rpm
workstück infeed, stepless 10-300 mm/min
tangential movement of workpiece 70 mm
electrics 380/50 V/Hz
weight of the m/c approx. 7.5 to


Accessories:


- dressing machine “REISHAUER AM 10, Year 1985”
- double disk dressing device “ Faessler”
- balancing machine, “Hoffmann”
- crowning attachment (inbuilt)
- change gears
- grinding wheels & flanges

43000
