Working travel in X/Y/Z [mm]
750/840 / 865
Speed (max.) in X/Y/Z [m/min]
90/75/90
Acceleration (max.) X/Y/Z [m/s²]
6/6/11
Feed force per spindle (max.) in X/Y/Z [kN]
6/6/10
Spindle pitch [mm]
800
Chip-to-chip time t1 as per VDI 2852 (min) [s]
2.6
Weight [kg]
23,000
3500x4700x3600
Tilting axes
A axis:
ØA: 1,000 mm
L: 1,770 mm
2 x 11
fluid connections
A-Achse G320
B axis:
ØB: 2 x 798 mm
H: 510 mm
2 x 9
fluid connections
B-Achse G320
A/B axis:
ØA: 1,000 mm
ØB: 2 x 798 mm
2 x 7
fluid connections
AB-Achse G320
Magazine variants
Double disc-type magazine with tool changer
HSK-A63:
