Flange bearing dia:250
Tail pipe dia:160mm
Fore bearing dia: 240mm
TRAVELS:
X – axis (module )
Y – axis 2450mm
w – axis 750 mm
Z: 600 mm
Rapid traverse X, Y/Z 5000mm , z: 3000mm /min
Speed 2,000 rpm
ACCURACY:
Positioning X, Y/Z +/- 0.015/mm
Repeatability X,Y,Z +/-0.005
Acting force:
X --2500-(4100)kg
Y --2500-(4100) kg
W --3000-(5000)kg
Z --3000-(5000)kg
Distance between x-axis and rail--2000
Distance between y-axis and rail --970
Distance between w-axis and rail --1800
Distance between spindle and rail--250
Spinlde power:--45kw
X- 18kw
Y- 7kw
W-12kw
Z-5.5 kw
Hydraulic power:3 kw
Radiator power:7kw
Digital control :2kw
Motor (AC )26KW
Max total power:127.5 kw
Travel of every column –12500mm，working height:2450mm ，3 working tables :2200*2200mm 1 working talble : 3200*3200mm， total weight of the machine:280 ton
Specifications:
Maker: KOLLMANN
Origin: Germany
New in: 1989
Condition: Still operating:
Control: 9 axis DRO
Price: Call us
Technical Date
Table size: 3200 x 8000mm
Between of columns: 3650mm
Passage of Height: 3200mm
Number of Head stock on Cross rail: Two
Number of Side Head stock on Column: Two
Power of Head stock: 50HP
Quill travel on Cross rail(Vertical Direction): 300mm
Quill travel on Columns(Horizontal Direction): 600mm
Spindle Taper: NT 60
1x Long angle milling attachment
Cutting and set-up tool is included in the machine.
