For Sale Listings
ALZMETALL, AC 28 CNC, VERTICAL, MACHINING CENTERS
  • Condition:Used
  • Category:MACHINING CENTERS
  • Type:VERTICAL
  • Manufacturer:ALZMETALL
  • Model:AC 28 CNC
  • YOM:1991
  • Location:Germany
  • Price:On request
  • Stock No:BAZ129
  • Control:Manual
  • ID:AS21619
Description:
Stock-No. 1106-BAZ129
Type of machine Machining Center - Vertical
Make ALZMETALL
Type AC 28 CNC
Year of manufacture 1991
Type of control konventionell
Storage location Pagus NL. Jena Germany
Country of origin Germany
Specifications:
Technical details
x-travel 450 mm
y-travel 300 mm
z-travel 180 mm
w-axis 380 mm
spindle head DIN 2079 SK 30
turning speed range: 50 - 5000 UpM
bore capacity in steel ST 60 32 mm
Boring power in GG 20 40 mm
threading: ST 60 M 24
threading GG 20 M30
traversing speed max X-, Y- u. W-Achse 5 m/min max.
traversing speed Z-Achse 3 m/min
tool changing time ca. 3 sec
max. workpiece weight 1,5 kg
distance spindle /table min /max 190 / 570 mm
surface area 650 x 300 mm
table load max. 150 kg
table height 770 mm
workpiece height max. 495 mm
distance spindle /table 190 - 570 mm
total power requirement 2,2 kW
weight of the machine ca. 1400 kg
dimensions of the machine ca. 1860 x 2050 x 2110 m
Dimensions:
1860 x 2050 x 2110 m
Weight:
1400 Kg
Dealer name:
Pagus Germany, Zchepplin
