Travels: X,Y,Z: 11.80" x 15.76" x 16.94"
(300mm x 400mm x 430mm)
Spindle Taper:: No. 40 Big Plus
Spindle Horsepower:: 20 HP
Spindle Speed:: 7,083 RPM (Optional 10,000)
Tool Changer:: 20
Control Type:: Fanuc i Series GX
Working Surface:: 23.6" x 15.8"
Floor Space:: 57.09" x 100.87"
(1,450mm x 2,562mm)
Approx Machine Weight:: 10,913 lbs (4,950 kg)
